21.0.0 | 21.0.1
Released 11-May-2023 Release Notes
ANALYSIS AND DESIGN OF
BUILDING SYSTEMS
LEARN ABOUT THE NEW FEATURES
IN THE LATEST RELEASE
NOW YOU CAN UPGRADE TO THE NEW VERSION OF THE TOP PROGRAM
Creation of models has never been easier - intuitive drawing commands allow for the rapid generation of floor and elevation framing.
CAD drawings can be converted directly into ETABS models or used as templates onto which ETABS objects may be overlaid.
The state-of-the-art SAPFire 64-bit solver allows extremely large and complex models to be rapidly analyzed.
Overview
The innovative and revolutionary new ETABS is the ultimate integrated software package for the structural analysis and design of buildings.
ETABS v21.0.0 – v21.0.1 enhancements
DETAILING
Detailing of concrete and steel structures, as well as the production and management of schematic design drawings, is now available from a new Detailing menu inside ETABS. It can now handle multiple towers as well.
Detailed reinforcement from beams, slabs, column stacks, and wall stacks can now be exported from ETABS to Autodesk® Revit® through the CSiXRevitTM 2023 plugin to Revit 2023.
STRUCTURAL MODEL
Tributary PT tendons are now accounted for in finite element-based design of slabs and cracked-slab deflection analysis (short- and long-term).
LOADING
Auto-wind load, auto-seismic load, and response-spectrum function based on NBCC 2020 have been added.
Auto-wind load, auto-seismic load, and response-spectrum function based on ASCE 7-22 have been added.
Loads assigned to null lines and null areas applied in any local or global direction are now transferred to the underlying structural floors. In earlier versions only loads in the gravity direction were transferred.
DESIGN
AS 4100:2020 steel frame design has been added.
Eurocode 4-2004 composite column design has been added.
OUTPUT AND DISPLAY
Cracked-section modifiers for beam and floor objects are now included in the database tables.
Nonlinear shear-material state and status output for general wall hinges is now available in the database tables, deformed shape display, and performance-check output.
DATABASE TABLES
Performance-check definitions can now be edited when the model is locked and selected for associated tabular output.
APPLICATION PROGRAMMING INTERFACE (API)
Support for .NET 6 has been added including a help topic in the “Key Concepts” folder.
ETABS v20.0.0 enhancements
SAPFire® Analysis Engine
CSI Solvers have been tried and tested by the industry for over 45 years.
The SAPFire Analysis Engine can support multiple 64-bit solvers for analysis optimization and perform both eigen analysis and Ritz analysis.
Parallelization options are available to take advantage of multiple processors.
ETABS offers a single user interface to perform modeling, analysis, design, and reporting. There is no limit to the number of model windows, model manipulation views, and data views.
Interactive Database Editing
CSI software stores model data and other information in database tables which may be edited directly through interactive database editing. This powerful feature allows models to be developed or edited quickly.
Utilize Interactive Design Capabilities to Maximize Efficiency
Design of steel frames, concrete frames, concrete slabs, concrete shear walls, composite beams, composite columns and steel joists can be performed based on a variety of US and international design codes.
BIM Interoperability
With CSI software, collaboration between different AEC teams is handled efficiently through compatibility with other BIM software.
ETABS 19.0.1|19.0.2 Enhancements
BIM Compatible
Increase your efficiency with bi-directional links to the industry leading BIM products.
International Design Codes
Whether the project is local or overseas, design codes from around the globe are available for steel, concrete, aluminum and cold form design codes.
Application Design Interface (API)
Employ the API to build custom plugins or powerful spreadsheets to increase efficiency in your workflow.
Analysis
Stiffness solution has been parallelized to further speed-up nonlinear static and direct-integration time-history load cases.
Tabular output for element nonlinear energy and base reactions is now much faster for load cases with many output steps.
Loading
NBCC 2015 wind load now supports the dynamic procedure for Open and Rough Terrain using the exposure factor Ce. Wind-load calculations are now available in the project report.
ETABS 19.0.0 Enhancements
Structural Model
The special requirements applied to the steel beam-column connections using the proprietary SidePlate® Systems have been updated to the latest version.
The Korean common rebar set is now available when defining reinforcing bar sizes.
Loading
Auto lateral loading has been added per the Korean KDS 41 17 00:2019 code, including seismic load and response-spectrum functions.
Auto lateral loading has been added per the NTC 2018 code, including wind load, seismic load, and response-spectrum functions.
Performance-Based Design
The event-to-event analysis method has been improved for better handling of equilibrium unbalances. Additional controls are available for this non-iterative method.
The speed of solution using the multi-threaded solver has been substantially increased for direct-integration time-history and other multi-step load cases.
The speed of solution using the multi-threaded solver has been substantially increased for direct-integration time-history and other multi-step load cases.
The recovery of plotted and tabular results from nonlinear static and direct-integration load cases is now significantly faster. Results include deformed shape, force and stress values, and hinge states.
The parametric PMM hinge has been enhanced to provide better convergence behavior in sensitive systems.
Analysis
Short-term and long-term cracked-deflections can now be calculated for concrete floors. The rebar used for the cracking calculation is based on either provided rebar, designed rebar, or a quick rebar overwrite.
Concrete Frame Design
Concrete frame design has been added per the ACI 318-19 code.
Composite column design has been added per the AISC 360-16 code.
Composite column design has been added per the AISC 360-16 code.
External Import/Export
Perform®3D model files can now be imported into ETABS. Most elements, cross-section properties, mass, loads, and load cases will be imported and translated. Certain types of nonlinear components will also be transferred, and a report will be produced of what was translated.
Perform®3D model files can now be exported from ETABS. Most structural objects, properties, loads, and load cases will be exported and translated. The ETABS model to be exported must meet modeling requirements of Perform®3D. A report will be produced of what was
Perform®3D model files can now be exported from ETABS. Most structural objects, properties, loads, and load cases will be exported and translated. The ETABS model to be exported must meet modeling requirements of Perform®3D. A report will be produced of what was
Slab Design - Reinforced Concrete and PT
Slab design has been added for reinforced-concrete and prestressed (PT) slabs per the following codes:
ACI 318-19
AS 3600-2018
Steel Frame Design
Numerous enhancements have been implemented for Russian SP 16.13330.2017 steel frame design.
Graphics
DirectX 2D is now used for plan and elevation views, providing faster and clearer rendering, improved line quality, and True Type fonts.
Application Programming Interface (API)
The API can now start and control instances of ETABS on remote computers, including the retrieval of results. This enables distributed processing for running large suites of Performance-based Design histories, extensive parameter studies, and Monte Carlo simulations.
Shear Wall Design
Shear wall design has been added per the ACI 318-19 code.
Database Tables
The automatic tabular output after analysis can now be directed to multiple files. Each file can produce a different set of tables and can apply to a different group.
Cloud Licensing
Cloud-based licensing is now standard for ETABS.
- Cloud-based server requires no setup
- Access licenses outside of company networks and VPNs
- Share licenses between users (non-simultaneous)
- Check-out a license to work offline
